Nightingale (Acuity Brands Lighting)
HSTL Surgical Suite Luminaire.
Configure
Add to project




RESOURCES
DESCRIPTION
The HSTL troffer uses dual-color channels and optional nLight® wired and wireless controls to deliver powerful illumination and color accuracy for a medical team's visual acuity. HSTL features static white in a single channel and a color option (red, amber or green) in a second channel dually-controlled, and can be used across in surgical suites, clean rooms and exam or procedure spaces. Available with up to 10,000 lumens in the 1x4, 12,000 lumens in the 2x2 and 30,000 lumens in the 2x4, HSTL has two distribution options: asymmetric and symmetric. With surface, grid and flange mounting options, HSTL is complete with machine-welded housing, frosted acrylic and polycarbonate lens options, and an integrated occupancy sensor option.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 1'2'L: 2'4'H: 5"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000KYellow/AmberRedGreen
- CRI80 90 95
- Watt(Approx)27-83 W27-101 W22-216 W
- Lumens(Approx)2744-8712 Lm3353-11604 Lm3311-29238 Lm
- OpticsDirectGeneral DiffusedAsymmetric/Wash
- Adjustable
- DimmingDim to 3-10%Dim to 1%Dim to <1%0-10VDALI
- Controls/NetworknLight®
- Power/VoltageIntegralUNV 120-277V120V277V347V
- Integral EmergencyEM Integral
- Lumen Maintenance120000 h
- CertificatesCSANSFBAA
- EnvironmentClean RoomAntimicrobial FinishIP66SurgicalHealthcare General
- Mounting TypeCeiling SurfaceCeiling RecessedDrywallT-Grid Ceiling
- HousingICChicago Plenum
- Housing Depth6 5/8 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
