MIN07P/MIN07R/MIN07S. MINEAR LINEAR 3/4'' Pendant, Recessed, Surface, Wall.
Configure
Add to project
RESOURCES
DESCRIPTION
From the Minear Collection of miniature, made-to-order luminaires, the 3/4" profile is available in recessed or surface mounting as well as in pendant configurations. Its slightly larger aperture allows for broader illumination while retaining a refined, unobtrusive presence.
MORE DESCRIPTION
SPECIFICATIONS
- DimensionsW: 3/4"L: Run length (inch)H: 7/8"
- Light SourceLED
- CCT/Color2700K3000K3500K4000K5000K
- CRI80 90
- Watt(Approx)1.8 W/Ft2.4 W/Ft4.1 W/Ft6 W/Ft7.3 W/Ft
- Lumens(Approx)150 Lm/Ft200 Lm/Ft350 Lm/Ft500 Lm/Ft600 Lm/Ft
- OpticsDirectGeneral Diffused
- Adjustable
- DimmingDim to 3-10%Dim to 1%Dim to <1%TRIAC/Forward/LeadingELV/Reverse/Trailing0-10VDALILutron Hi-lume EcoSystem (LDE1)eldoLED ECO 0-10VeldoLED SOLO 0-10V
- Controls/Network
- Power/VoltageRemoteUNV 120-277V120V277V347V
- Integral Emergency
- Lumen Maintenance60000 h
- CertificatesETL
- EnvironmentDamp
- Mounting TypePendantCeiling SurfaceCeiling RecessedWall SurfaceWall Recessed
- HousingIC
- Housing Depth1 ''
SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
-
Lead timeMIN07
