H. E. Williams, Inc.
75W. Wide Lens Narrow Strip LED.
 Configure
 Add to project
H. E. Williams, Inc.. 75W. Wide Lens Narrow Strip LED.
H. E. Williams, Inc.. 75W. Wide Lens Narrow Strip LED.
H. E. Williams, Inc.. 75W. Wide Lens Narrow Strip LED.
RESOURCES
DESCRIPTION
  • Ideal for data centers, commercial offices, schools and industrial spaces
  • Wide lens shape provides 13% uplight to illuminate dark ceilings
  • High ambient option for extreme environments
  • HE option delivers superior efficacies up to 182 lm/W
  • Row applications produce continuous light with minimal interruption
  • Diffuse acrylic lens enhances uniformity and minimizes glare
  • Variety of mounting accessories for surface and suspended applications
  • Six standard finish options and a wide selection of custom colors complement the architectural elements of any space
  • 2′, 3′, 4′, and 8′ lengths available
  • Wireless in-fixture control solutions available
  • Support human-centric design with adaptive, individualized lighting using tunable white light
  • Build America, Buy America and Buy American Act compliant
  • Wireless in-fixture control solutions available
  • Made Right Here® in the USA
MORE DESCRIPTION
SPECIFICATIONS
  • Dimensions
    W: 4 1/2"
    L: 22 1/2"33 9/16"44 5/8"89 1/4"
  • Light Source
    LED
  • CCT/Color
    2700K3000K3500K4000K5000KTunable White
  • CRI
    80 90
  • Watt(Approx)
    10.8 W18.2 W19.7 W21.3 W28.2 W31.4 W33 W35.3 W48.2 W42.3 W56.2 W68.3 W65.9 W87.9 W112.4 W136.5 W
  • Lumens(Approx)
    1511 Lm2470 Lm2936 Lm2916 Lm4124 Lm3885 Lm4867 Lm6259 Lm5994 Lm5520 Lm8098 Lm9640 Lm9568 Lm12353 Lm16197 Lm19281 Lm
  • Optics
    DirectGeneral Diffused
  • Adjustable
  • Dimming
    Dim to 3-10%Dim to 1%Step DimNon-DimTRIAC/Forward/LeadingELV/Reverse/Trailing0-10VDALILutron Hi-lume EcoSystem (LDE1)DMX
  • Controls/Network
    Integral Sensor
  • Power/Voltage
    IntegralPoEUNV 120-277V120V208V220-240V277V347V
  • Integral Emergency
  • Lumen Maintenance
    72000 h
  • Certificates
    CSAMade in USABAA
  • Environment
    Damp
  • Mounting Type
    Pendant
  • Housing
  • Housing Depth
 SKU configuration, design parameters and all files available for download shall always be verified with manufacturer. LightAZ is not responsible for any errors or omissions for product specified on our website. Refer to our TERMS of SERVICES for more information.
